Home / Products / HEATING COOLING HVAC DHW / MOTORISED VALVE WITH BUILT-IN ELECTRONICS AND ANTILEGIONELLA - HVAC / MIXING MOTORISED VALVES - FIXED POINT

DIAMIX motorised valve – MMM vertical mixed outlet

Technical data
Download
Description
Use
Codice /
Code 		Tensione /
P. supply		Connessione /
Connection		DNKVsPNΔP
DIAMIXNB230 V
50/60 Hz		3/4"2011,51616
bar
DIAMIXNC230 V
50/60 Hz		1"2518,31616
bar
TECHNICAL DATASHEETUSER'S MANUAL

DOMESTIC HOT WATER / UNDERFLOOR HEATING / REGULATION IN GENERAL

Mixing thermoregulating actuator with electronics onboard

Class protection IP67

Semiconductor temperature sensor

3-way BRASS ball valve, MMM with caps and tangs PN16, full bore

EXAMPLE OF USE (ITA) - ANTICONDENSING FUNCTIONEXAMPLE OF USE (ITA) - HEATINGEXAMPLE OF USE (ITA) - HEATING PLANT WITH VERTICAL MIXING VALVEEXAMPLE OF USE (ITA) - HEATING PLANT WITH MIXING VALVEEXAMPLE OF USE (ITA) - SANITARY WATER

DIAMIX motorised valve – FFF vertical mixed outlet

Technical data
Download
Description
Use
Codice /
Code 		Tensione /
P. supply		Connessione /
Connection		DNKVsPNΔP
DIAMIXNFA230 V
50/60 Hz		1/2"1562525
bar
DIAMIXNFB230 V
50/60 Hz		3/4"2011,51616
bar
DIAMIXNFC230 V
50/60 Hz		1"2518,31616
bar
TECHNICAL DATASHEETUSER'S MANUAL

DOMESTIC HOT WATER / UNDERFLOOR HEATING / REGULATION IN GENERAL

Mixing thermoregulating actuator with electronics onboard

Class protection IP67

Semiconductor temperature sensor

3-way BRASS ball valve, FFF vertical/horizontal, full bore

EXAMPLE OF USE (ITA) - ANTICONDENSING FUNCTIONEXAMPLE OF USE (ITA) - HEATINGEXAMPLE OF USE (ITA) - HEATING PLANT WITH VERTICAL MIXING VALVEEXAMPLE OF USE (ITA) - HEATING PLANT WITH MIXING VALVEEXAMPLE OF USE (ITA) - SANITARY WATER

COMPAMIX motorised valve – FFF vertical mixed outlet

Technical data
Download
Description
Use
Codice /
Code 		Tensione /
P. supply		Connessione /
Connection		DNKVsPNΔP
COMPAMIXD230 V
50 Hz		1"1/43227,21010
bar
COMPAMIXE230 V
50 Hz		1"1/24047,3106
bar
COMPAMIXF230 V
50 Hz		2"5073104
bar
TECHNICAL DATASHEETUSER'S MANUAL

DOMESTIC HOT WATER / UNDERFLOOR HEATING / REGULATION IN GENERAL

Mixing thermoregulating actuator with electronics onboard

Class protection IP67

Semiconductor temperature sensor

3-way FFF BRASS ball valve, full bore

EXAMPLE OF USE (ITA) - ANTICONDENSING FUNCTIONEXAMPLE OF USE (ITA) - HEATINGEXAMPLE OF USE (ITA) - HEATING PLANT WITH VERTICAL MIXING VALVEEXAMPLE OF USE (ITA) - HEATING PLANT WITH MIXING VALVEEXAMPLE OF USE (ITA) - SANITARY WATER

4 seconds DIAMIX motorised valve – FFF vertical mixed outlet

Technical data
Download
Description
Use
Codice /
Code 		Tensione /
P. supply		Connessione /
Connection		DNKVsPNΔP
DIAMIXNFAQ230 V
50/60 Hz		1/2"1562525
bar
TECHNICAL DATASHEETUSER'S MANUAL

DOMESTIC HOT WATER / UNDERFLOOR HEATING / REGULATION IN GENERAL

Mixing thermoregulating actuator with electronics onboard

Class protection IP67

Semiconductor temperature sensor

3-way BRASS ball valve, FFF, full bore

EXAMPLE OF USE (ITA) - WITHOUT DHW RECIRCULATION

DIAMIX motorised valve – FFF horizontal in line mixed outlet

Technical data
Download
Description
Use
Codice /
Code 		Tensione /
P. supply		Connessione /
Connection		DNKVsPNΔP
DIAMIXNFAM230 V
50/60 Hz		1/2"156163,5
bar
DIAMIXNFBM230 V
50/60 Hz		3/4"204,8163,5
bar
DIAMIXNFCM230 V
50/60 Hz		1"258,6163,5
bar
DIAMIXNFDM230 V
50/60 Hz		1"1/43212,8163,5
bar
DIAMIXNFEM230 V
50/60 Hz		1"1/24011,5163,5
bar
DIAMIXNFFM230 V
50/60 Hz		2"5019,5163,5
bar
TECHNICAL DATASHEETUSER'S MANUAL

DOMESTIC HOT WATER / UNDERFLOOR HEATING / REGULATION IN GENERAL

Mixing thermoregulating actuator with electronics onboard

Class protection IP67

Semiconductor temperature sensor

3-way BRASS ball valve, FFF, PN16

EXAMPLE OF USE (ITA) - ANTICONDENSING FUNCTIONEXAMPLE OF USE (ITA) - HEATINGEXAMPLE OF USE (ITA) - HEATING PLANT WITH VERTICAL MIXING VALVEEXAMPLE OF USE (ITA) - HEATING PLANT WITH MIXING VALVEEXAMPLE OF USE (ITA) - SANITARY WATER

DIAMIX motorised valve – vertical in line mixed outlet

Technical data
Download
Description
Use
Codice /
Code 		Tensione /
P. supply		Connessione /
Connection		DNKVsPNΔP
DIAMIXNFBV230 V
50/60 Hz		3/4" MMM206,7163,5
bar
DIAMIXNFCV230 V
50/60 Hz		1" MMM2511,4163,5
bar
DIAMIXNFDV230 V
50/60 Hz		1"1/4 MMM3217,5163,5
bar
DIAMIXNFEV230 V
50/60 Hz		1"1/2 FFF4026,8163,5
bar
DIAMIXNFFV230 V
50/60 Hz		2" FFF5052,6163,5
bar
TECHNICAL DATASHEETUSER'S MANUAL

DOMESTIC HOT WATER / UNDERFLOOR HEATING / REGULATION IN GENERAL

Mixing thermoregulating actuator with electronics onboard

Class protection IP67

Semiconductor temperature sensor

3-way BRASS ball valve, PN16

EXAMPLE OF USE (ITA) - ANTICONDENSING FUNCTIONEXAMPLE OF USE (ITA) - HEATINGEXAMPLE OF USE (ITA) - HEATING PLANT WITH VERTICAL MIXING VALVEEXAMPLE OF USE (ITA) - HEATING PLANT WITH MIXING VALVEEXAMPLE OF USE (ITA) - SANITARY WATER

Diamix/Compamix accessories

Technical data
Download
Descrizione accessorio
Accessories description		Aggiungi al codice
Add at code		Note
Notes
Sonda ad immersione in ottone
Brass immersion probe		KØ 1/8" - pozzetto non incluso
Ø 1/8" pocket not included
Versione 24V 50Hz
24V 50Hz version		04
Distanziale per al coibentazione
Spacer for insulation		D1Diamix
Compamix
Distanziale per la coibentazione e apertura manuale
Spacer for insulation manual override		D2Diamix
Compamix
TECHNICAL DATASHEETUSER'S MANUAL
