M-Bus Master

Technical data
Description
CodeProduct's Description
MBUSLC1Level converter

M-Bus level converter for managing up to 60 devices. Stand-alone field device for data collection from M-Bus meter to PC by using a USB connection. The M-Bus slave interface can be used as repeater in order to extend the M-Bus network up to additional 60 devices. 24 V ac/dc power supply, max. power consumption 7W.

RTU M-Bus

Technical data
Description
CodeProduct's Description
MBWRTU1TRTU M-Bus, 20 devices

RTU M-Bus for managing up to 20 devices with datalogger function. Stand-alone field device for data collection from M-Bus meter by using a WEB interface. Integrated display for setup and data reading. It can be extended up to 250 devices by adding Level converter MBUSLC1. Pre-set for the M-Bus WIRELESS reading. 24 V ac/dc power supply, max. power consumption 7,5 W.

Datalogger

Technical data
Description
CodeProduct's Description
MBUSRTU1RTU Datalogger

RTU Datalogger for data collection and storage by using a WEB interface, which allows reading of the meters, report generation and remote consultation of old readings. Integrated display for setup and data reading. It can manage up to 250 M-Bus devices. 24 V ac/dc power supply, max. power consumption 3 W.
Note: to be coupled with Level Converter MBUSLC1

Level Coverter M-Bus

Technical data
Description
CodeDescription
MBUSLC250Level converter, 250 devices

Level Converter M-Bus for the management of up to 250 devices. Stand-alone field module for M-Bus counter data reading through RS232, RS485 (exclusive) ports, M-Bus slave interface to be used as a repeater station and add another 250 devices to the M-Bus network. 230V AC power supply (power supply included).

Smart gateway

Technical data
Description
CodeDescription
MBWSGWireless Smart Gateway M-Bus 200 devices - weekly transmission

Data concentrator for the acquisition of RF device signals according to the M-Bus WIRELESS 868Mhz standard. It can cover a distance of 250 meters outdoors and 25 meters indoors. Configurable with Global Hub, IoT Platform. Built-in GPRS modem. It can manage up to 200 devices with weekly transmission (different intervals upon request). It supports the WIRELESS M-Bus S, T & C modes. The coverage range can be extended with M-Bus WIRELESS (MBWRPT) repeaters. Integrated SIM CARD with one year of operation. 230V 50Hz power supply.

Repeater

Technical data
Description
CodeDescription
MBWRPTRepeater Wireless

Unidirectional Wireless M-Bus 868Mhz repeater. Single-hop support. Software-configurable. 230V 50Hz power supply.

OPTIONAL: ROUTER 4G

Technical data
Description
CodeProduct's Description
MBRUT240VRouter 4G

Compact 4G router with Ethernet and WIRELESS interface. The device offers a secure and stable Internet connection for applications which use the RutOS software and security features such as OpenVPN, Ipsec, Firewall, Hotspot, SMS control and RMS support. Power supply, GSM antenna, Wi-Fi antenna included.

Note: to be matched with MBUSRTU1 or MBUSRTU1T

OPTIONAL: FEEDER 24V DC 12W

Technical data
Description
CodeProduct's Description
AL24VDCPower supply

24V DC 12W feeder from DIN bar ( unit dimesions) lout= 500 mA
Note: It can support n°1 Level converter + n°1 RTU Datalogger
