Bitherm
Technical data
Description
| Product Type | Model |
|---|---|
| Hydraulic interface unit for DHW production and complete hydraulic separation on heating circuit with temperature control | Bitherm |
| COMPONENTS | |
| Strainer | |
| DHW temperature probe | |
| Flowmeter | |
| Flow static limiter | |
| Heat exchanger for heating circuit | |
| Heat exchanger for sanitary circuit | |
| Sintesi 2-way modulating motorised valve on sanitary circuit | |
| Sintesi 2-way ON/OFF motorised valve on primary circuit | |
| Electronics management box | |
| Energy meter, M-Bus reading / Ultrasonic energy meter | |
| Sanitary water meter, M-Bus reading | |
| Pump | |
| Safety valve | |
| Expansion vessel | |
| Manometer | |
| Filling point | |
| Cover | |
| Inlet manual interception valves | Optional |
| Outlet manual interception valves | Optional |
| Temperature control on heating circuit | Optional |
| Pump for sanitary circuit | Optional |
| Plant balancing with static balancing valve / Plant balancing with dynamic balancing valve / Plant balancing with DPCV / Plant balancing with Modflow - electronic flow control | Optional |
| System start-up and technical support | Optional |
Direct energy metering
Centralised heating plant management
Hydraulic separation
Two plated heat exchangers for DHW production and heating
Hot and cold sanitary water lines
For heating plant with condensing boiler
DIATECH S
Technical data
Download
Description
| Product Type | Model |
|---|---|
| Hydraulic interface unit for heating and DHW production | Diatech S |
| COMPONENTS | |
| Strainer | |
| Manual interception valves (version with template box) | |
| DHW temperature probe | |
| Flowmeter | |
| Flow static limiter | |
| Heat exchanger | |
| Sintesi 2-way modulating motorised valve on sanitary circuit | |
| Sintesi 2-way ON/OFF motorised valve on primary circuit | |
| Electronics management box | |
| Energy meter, M-Bus reading / Ultrasonic energy meter | |
| Sanitary water meter, M-Bus reading | |
| Treated and/or pre-heated sanitary water meter, M-Bus reading | Optional |
| Template box (recessed installation) | Optional |
| White casing (wall hanging) | Optional |
| Pump on primary circuit | Optional |
| Recirculation on primary circuit | Optional |
| Plant balancing with static balancing valve / Plant balancing with dynamic balancing valve / Plant balancing with DPCV / Plant balancing with Modflow - electronic flow control | Optional |
| Non-return valve | Optional |
| System start-up and technical support | Optional |
Direct energy metering
Centralised heating plant management
Plated heat exchanger for DHW production
Hot and cold sanitary water lines
For traditional heating plant
Diatech SR
Technical data
Description
| Product Type | Model |
|---|---|
| Hydraulic interface unit for heating and cooling systems and DHW production | Diatech SR |
| COMPONENTS | |
| Strainer | |
| Inlet manual interception valves | |
| Outlet manual interception valves | |
| DHW temperature probe | |
| Flowmeter | |
| Flow static limiter | |
| Heat exchanger | |
| Sintesi 2-way modulating motorised valve on sanitary circuit | |
| Sintesi 2-way ON/OFF motorised valve on primary circuit | |
| Electronics management box | |
| Energy meter, M-Bus reading / Ultrasonic energy meter | |
| Sanitary water meter, M-Bus reading | |
| Energy meter, M-Bus reading for cooling / Ultrasonic energy meter for cooling | |
| Sintesi 2-way ON/OFF motorised valve on low temperature heating circuit | |
| Cooling line insulation | |
| Template box | |
| Door and frame | |
| Plant balancing with static balancing valve / Plant balancing with dynamic balancing valve / Plant balancing with DPCV / Plant balancing with Modflow - electronic flow control | Optional |
| System start-up and technical support | Optional |
Direct energy metering
Centralised heating plant management
Plated heat exchanger for DHW production
Hot and cold sanitary water lines
For traditional heating plant
DIATECH LF
Technical data
Download
Description
| Product Type | Model |
|---|---|
| Hydraulic interface unit for heating and DHW production with increased heat exchanger for condensation plants | Diatech LF |
| COMPONENTS | |
| Strainer | |
| Manual interception valves (version with template box) | |
| DHW temperature probe | |
| Flowmeter | |
| Flow static limiter | |
| Heat exchanger | |
| Sintesi 2-way modulating motorised valve on sanitary circuit | |
| Sintesi 2-way ON/OFF motorised valve on primary circuit | |
| Electronics management box | |
| Energy meter, M-Bus reading / Ultrasonic energy meter | |
| Sanitary water meter, M-Bus reading | |
| Treated and/or pre-heated sanitary water meter, M-Bus reading | Optional |
| Template box (recessed installation) | Optional |
| White casing (wall hanging) | Optional |
| Pump on primary circuit / Recirculation on primary circuit | Optional |
| Plant balancing with static balancing valve / Plant balancing with dynamic balancing valve / Plant balancing with DPCV / Plant balancing with Modflow - electronic flow control | Optional |
| Non-return valve | Optional |
| System start-up and technical support | Optional |
Direct energy metering
Centralised heating plant management
Plated heat exchanger for DHW production
Hot and cold sanitary water lines
For heating plant with condensing boiler
Diatech L
Technical data
Description
| Product Type | Model |
|---|---|
| Hydraulic interface unit for heating and DHW and DCW production with in-line connection on the inferior side | Diatech L |
| COMPONENTS | |
| Strainer | |
| Inlet manual interception valves | |
| Outlet manual interception valves | |
| DHW temperature probe | |
| Flowmeter | |
| Flow static limiter | |
| Heat exchanger | |
| Sintesi 2-way modulating motorised valve on sanitary circuit | |
| Sintesi 2-way ON/OFF motorised valve on primary circuit | |
| Electronics management box | |
| Energy meter, M-Bus reading / Ultrasonic energy meter | |
| Sanitary water meter, M-Bus reading | |
| Template box | |
| Door and frame | |
| Plant balancing with static balancing valve / Plant balancing with dynamic balancing valve / Plant balancing with DPCV / Plant balancing with Modflow - electronic flow control | Optional |
| System start-up and technical support | Optional |
Direct energy metering
Centralised heating plant management
Plated heat exchanger for DHW production
Hot and cold sanitary water lines
For traditional heating plant
In-line connection from the bottom
DIATECH BT/HT
Technical data
Description
| Product Type | Model |
|---|---|
| Hydraulic interface unit for management in high and low temperature and DHW production | Diatech BT/HT |
| COMPONENTS | |
| Strainer | |
| Inlet manual interception valves | |
| Outlet manual interception valves | |
| DHW temperature probe | |
| Flowmeter | |
| Flow static limiter | |
| Heat exchanger | |
| Sintesi 2-way modulating motorised valve on sanitary circuit | |
| Sintesi 2-way ON/OFF motorised valve on primary circuit | |
| Electronics management box | |
| Energy meter, M-Bus reading / Ultrasonic energy meter | |
| Sanitary water meter, M-Bus reading | |
| Template box | |
| Door and frame | |
| Low temperature circuit pump | |
| Sintesi 2-way modulating motorised valve on low temperature circuit | |
| Safety thermostat for low temperature circuit | |
| Low temperature probe | |
| Non-return valve | |
| Plant balancing with static balancing valve / Plant balancing with dynamic balancing valve / Plant balancing with DPCV / Plant balancing with Modflow - electronic flow control | Optional |
| System start-up and technical support | Optional |
Direct energy metering
Centralised heating plant management
Electronic management of one low temperature line with pump
Plated heat exchanger for DHW production
Hot and cold sanitary water lines
For traditional heating plant
