DIASEP air separators – square connections

Model
Download
Description
Codice / Code Attacchi / ConnectionsTipo Attacco / Connection TypeCorpo / Body
S001Ø 1"filettati / threaded4"
S114Ø 1"1/4filettati / threaded5"
S112Ø 1"1/2filettati / threaded6"
S002Ø 2"filettati / threaded8"
S212DN 65flangiati PN 10-16 / flanged PN 10-1610"
S003DN 80flangiati PN 10 / flanged PN 1012"
S004DN 100flangiati PN 10-16 / flanged PN 10-1616"
S005DN 125flangiati PN 10-16 / flanged PN 10-16500 mm
S006DN 150flangiati PN 10-16 / flanged PN 10-16600 mm
S008DN 200flangiati PN 10 / flanged PN 10700 mm

Air separator for heating plants

Square connections

Carbon steel

Out-of-standard products can be realised according to Customer’s requirements

Diafil – Magnetic Filter

Model
Download
Description
Use
Codice /
Code
Attacchi /
Connections
Corpo /
Body
Grado di Filtrazione /
Degree of Filtration
Filettati / Threaded
FT001Ø 1"4"900 μm
FT114Ø 1"1/44"900 μm
FT112Ø 1"1/25"900 μm
FT002Ø 2"5"900 μm
Flangiati PN 10-16 /
Flanged PN 10-16
FT212DN 658"900 μm
FT003DN 808"900 μm
FT004DN 10010"900 μm

DIAFIL is the filter for heating plant for the prevention of circulators and other system components.

Provided with magnet and manual drain for periodic cleaning.

It can measure the differential pressure thanks to its threaded connections.

Deaerators

Model
Download
Description
CodeBodyMain ConnectionTool Connections
DI0123"1/2"3/8"

The DEAERATOR is specifically used for eliminating air in heating systems. It can be fitted with automatic release and manual release.

Tools and safety devices are not included.

Manifolds with integrated hydraulic compensator: DIASYS

Model
Download
Description
Use
Codice /
Code
Zone /
Zones
Attacchi Principali /
Main Connections
Attacchi Derivazioni /
Outlet Connections
i
COLLETTORE
MANIFOLD
CCI0234GR21"1/4G 1"125 mm
CCI0334GR31"1/4G 1"125 mm
CCI3134GR3+1 *1"1/4G 1"125 mm
CCI3234GR3+2 *1"1/4G 1"125 mm
COIBENTAZIONE
INSULATION
CBCCI023421"1/4G 1"125 mm
CBCCI033431"1/4G 1"125 mm
CBCCI31343+1 *1"1/4G 1"125 mm
CBCCI32343+2 *1"1/4G 1"125 mm

125 interaxis manifold for pump unit with integrated hydraulic compensator with nut outlet

Carbon steel

Insulation

Fixing kit

Out-of-standard products can be realised according to Customer’s requirements

Threaded male Ø 1″ outlet

Model
Download
Description
Use
Codice /
Code
Zone /
Zones
Attacchi Principali /
Main Connections
Attacchi Derivazioni /
Outlet Connections
i
COLLETTORE 1" M
1" M MANIFOLD
C02D0121"1/21" M125 mm
C03D0131"1/21" M125 mm
C04D0141"1/21" M125 mm
C05D0151"1/21" M125 mm
C06D0161"1/21" M125 mm
COIBENTAZIONE 1" M
1" M INSULATION
CBC02D0121"1/21" M125 mm
CBC03D0131"1/21" M125 mm
CBC04D0141"1/21" M125 mm
CBC05D0151"1/21" M125 mm
CBC06D0161"1/21" M125 mm

125 mm interaxis dual manifold for heating plant with threaded outlet

Carbon steel

Insulation

Fixing kit

Out-of-standard products can be realised according to Customer’s requirements

Nut female Ø 1″¼ outlet

Model
Download
Description
Use
Codice /
Code
Zone /
Zones
Attacchi Principali /
Main Connections
Attacchi Derivazioni /
Outlet Connections
i
COLLETTORE 1"1/4 F
1"1/4 F MANIFOLD
C02D01GR21"1/2G 1"1/4125 mm
C03D01GR31"1/2G 1"1/4125 mm
C04D01GR41"1/2G 1"1/4125 mm
C05D01GR51"1/2G 1"1/4125 mm
C06D01GR61"1/2G 1"1/4125 mm
COIBENTAZIONE 1"1/4 F
1"1/4 F INSULATION
CBC02D0121"1/2G 1"1/4125 mm
CBC03D0131"1/2G 1"1/4125 mm
CBC04D0141"1/2G 1"1/4125 mm
CBC05D0151"1/2G 1"1/4125 mm
CBC06D0161"1/2G 1"1/4125 mm

125 mm interaxis dual manifold for heating plant with nut outlet

Carbon steel

Insulation

Fixing kit

Out-of-standard products can be realised according to Customer’s requirements

Threaded male Ø ¾” outlet

Model
Download
Description
Use
Codice /
Code
Zone /
Zones
Attacchi Principali /
Main Connections
Attacchi Derivazioni /
Outlet Connections
i
COLLETTORE 3/4" M
3/4" M MANIFOLD
C02D3421"1/43/4" M125 mm
C03D3431"1/43/4" M125 mm
C04D3441"1/43/4" M125 mm
C05D3451"1/43/4" M125 mm
C06D3461"1/43/4" M125 mm
COIBENTAZIONE 3/4" M
3/4" M INSULATION
CBC02D3421"1/43/4" M125 mm
CBC03D3431"1/43/4" M125 mm
CBC04D3441"1/43/4" M125 mm
CBC05D3451"1/43/4" M125 mm
CBC06D3461"1/43/4" M125 mm

125 mm interaxis dual manifold for heating plant with threaded outlet

Carbon steel

Insulation

Fixing kit

Out-of-standard products can be realised according to Customer’s requirements

Nut female Ø 1″ outlet

Model
Download
Description
Use
Codice /
Code
Zone /
Zones
Attacchi Principali /
Main Connections
Attacchi Derivazioni /
Outlet Connections
i
COLLETTORE 1" F
1" F MANIFOLD
C02D34GR21"1/4G 1"125 mm
C03D34GR31"1/4G 1"125 mm
C04D34GR41"1/4G 1"125 mm
C05D34GR51"1/4G 1"125 mm
C06D34GR61"1/4G 1"125 mm
COIBENTAZIONE 1" F
1" F INSULATION
CBC02D3421"1/4G 1"125 mm
CBC03D3431"1/4G 1"125 mm
CBC04D3441"1/4G 1"125 mm
CBC05D3451"1/4G 1"125 mm
CBC06D3461"1/4G 1"125 mm

125 mm interaxis dual manifold for heating plant with nut outlet

Carbon steel

Insulation

Fixing kit

Out-of-standard products can be realised according to Customer’s requirements

Threaded male Ø 1″ outlet

Model
Download
Description
Use
Codice /
Code
Zone /
Zones
Attacchi Principali /
Main Connections
Attacchi Derivazioni /
Outlet Connections
i
COLLETTORE 1"M
1" M MANIFOLD
C21D012+11"1/21" M125 mm
C22D012+21"1/21" M125 mm
C31D013+11"1/21" M125 mm
C32D013+21"1/21" M125 mm
C33D013+31"1/21" M125 mm
C41D014+11"1/21" M125 mm
C42D014+21"1/21" M125 mm
C51D015+11"1/21" M125 mm
COIBENTAZIONE 1"M
1"M INSULATION
CBC21D012+11"1/21" M125 mm
CBC22D012+21"1/21" M125 mm
CBC31D013+11"1/21" M125 mm
CBC32AD013+21"1/21" M125 mm
CBC33D013+31"1/21" M125 mm
CBC41D014+11"1/21" M125 mm
CBC42D014+21"1/21" M125 mm
CBC51D015+11"1/21" M125 mm

125 mm interaxis dual opposed manifold for heating plant with threaded outlet

Carbon steel

Insulation

Fixing kit

Out-of-standard products can be realised according to Customer’s requirements

Nut female Ø 1″¼ outlet

Model
Download
Description
Use
Codice /
Code
Zone /
Zones
Attacchi Principali /
Main Connections
Attacchi Derivazioni /
Outlet Connections
i
COLLETTORE 1"1/4 F
1"1/4 F MANIFOLD
C21D01GR2+11"1/2G 1"1/4125 mm
C22D01GR2+21"1/2G 1"1/4125 mm
C31D01GR3+11"1/2G 1"1/4125 mm
C32D01GR3+21"1/2G 1"1/4125 mm
C33D01GR3+31"1/2G 1"1/4125 mm
C41D01GR4+11"1/2G 1"1/4125 mm
C42D01GR4+21"1/2G 1"1/4125 mm
C51D01GR5+11"1/2G 1"1/4125 mm
COIBENTAZIONE 1"1/4 F
1"1/4 F INSULATION
CBC21D012+11"1/2G 1"1/4125 mm
CBC22D012+21"1/2G 1"1/4125 mm
CBC31D013+11"1/2G 1"1/4125 mm
CBC32D013+21"1/2G 1"1/4125 mm
CBC33D013+31"1/2G 1"1/4125 mm
CBC41D014+11"1/2G 1"1/4125 mm
CBC42D014+21"1/2G 1"1/4125 mm
CBC51D015+11"1/2G 1"1/4125 mm

125 mm interaxis dual opposed manifold for heating plant with nut outlet

Carbon steel

Insulation

Fixing kit

Out-of-standard products can be realised according to Customer’s requirements

Threaded male Ø ¾” outlet

Model
Download
Description
Use
Codice /
Code
Zone /
Zones
Attacchi Principali /
Main Connections
Attacchi Derivazioni /
Outlet Connections
i
COLLETTORE 3/4" M
3/4" M MANIFOLD
C21D342+11"1/43/4" M125 mm
C22D342+21"1/43/4" M125 mm
C31D343+11"1/43/4" M125 mm
C32D343+21"1/43/4" M125 mm
C33D343+31"1/43/4" M125 mm
C41D344+11"1/43/4" M125 mm
C42D344+21"1/43/4" M125 mm
C51D345+11"1/43/4" M125 mm
COIBENTAZIONE 3/4" M
3/4" M INSULATION
CBC21D342+11"1/43/4" M125 mm
CBC22D342+21"1/43/4" M125 mm
CBC31D343+11"1/43/4" M125 mm
CBC32D343+21"1/43/4" M125 mm
CBC33D343+31"1/43/4" M125 mm
CBC41D344+11"1/43/4" M125 mm
CBC42D344+21"1/43/4" M125 mm
CBC51D345+11"1/43/4" M125 mm

125 mm interaxis dual opposed manifold for heating plant with threaded outlet

Carbon steel

Insulation

Fixing kit

Out-of-standard products can be realised according to Customer’s requirements

Nut female Ø 1″ outlet

Model
Download
Description
Use
Codice /
Code
Zone /
Zones
Attacchi Principali /
Main Connections
Attacchi Derivazioni /
Outlet Connections
i
COLLETTORE 1" F
1" F MANIFOLD
C21D34GR2+11"1/4G 1"125 mm
C22D34GR2+21"1/4G 1"125 mm
C31D34GR3+11"1/4G 1"125 mm
C32D34GR3+21"1/4G 1"125 mm
C33D34GR3+31"1/4G 1"125 mm
C41D34GR4+11"1/4G 1"125 mm
C42D34GR4+21"1/4G 1"125 mm
C51D34GR5+11"1/4G 1"125 mm
COIBENTAZIONE 1" F
1" F INSULATION
CBC21D342+11"1/4G 1"125 mm
CBC22D342+21"1/4G 1"125 mm
CBC31D343+11"1/4G 1"125 mm
CBC32D343+21"1/4G 1"125 mm
CBC33D343+31"1/4G 1"125 mm
CBC41D344+11"1/4G 1"125 mm
CBC42D344+21"1/4G 1"125 mm
CBC51D345+11"1/4G 1"125 mm

125 mm interaxis dual opposed manifold for heating plant with nut outlet

Carbon steel

Insulation

Fixing kit

Out-of-standard products can be realised according to Customer’s requirements

DIACOL 140

Model
Download
Description
Use
Codice /
Code
Zone /
Zones
Attacchi Principali /
Main Connections
Attacchi Derivazioni /
Outlet Connections
i
COLLETTORE
MANIFOLD
C2T21"1/41"140 mm
C3T31"1/21"140 mm
C4T41"1/21"140 mm
C5T52"1"140 mm
C6T62"1"140 mm
COIBENTAZIONE
INSULATION
CBC2T21"1/41"140 mm
CBC3T31"1/21"140 mm
CBC4T41"1/21"140 mm
CBC5T52"1"140 mm
CBC6T62"1"140 mm

140 mm interaxis dual manifold for heating plant with threaded outlet

Carbon steel

Insulation

Fixing kit

Out-of-standard products can be realised according to Customer’s requirements

DIASEP air separators – in-line connections

Model
Download
Description
Codice / Code Attacchi / ConnectionsTipo Attacco / Connection TypeCorpo / Body
SL001Ø 1"filettati / threaded4"
SL114Ø 1"1/4filettati / threaded5"
SL112Ø 1"1/2filettati / threaded6"
SL002Ø 2"filettati / threaded8"
SL212DN 65flangiati PN 10-16 / flanged PN 10-1610"
SL003DN 80flangiati PN 10 / flanged PN 1012"
SL004DN 100flangiati PN 10-16 / flanged PN 10-1616"
SL005DN 125flangiati PN 10-16 / flanged PN 10-16500 mm
SL006DN 150flangiati PN 10-16 / flanged PN 10-16600 mm
SL008DN 200flangiati PN 10 / flanged PN 10700 mm

Air separator for heating plants

In-line connections

Carbon steel

Out-of-standard products can be realised according to Customer’s requirements

DIAS stainless steel manifolds

Model
Download
Description
Codice / Code Stacchi / OutlestAttacchi Principali /
Main Connections
Attacchi Derivazioni /
Outlet Connections
CX112122021"1/2 M1/2" F
CX11212222+21"1/2 M1/2" F
CX112123031"1/2 M1/2" F
CX11212333+31"1/2 M1/2" F
CX112124041"1/2 M1/2" F
CX11212444+41"1/2 M1/2" F

Unità di interfaccia per acqua sanitaria

Dedicata alla produzione di ACS

Con scambiatore a piastre per produzoine ACS

Con regolatore elettronico modulante

Hydrocyclonic deposit separator with integrated magnet

Model
Download
Description
Use
Codice / Code Attacchi / ConnectionsCorpo / Body
Filettati / Threaded
DFI001Ø 1"4"
DFI114Ø 1"1/45"
DFI112Ø 1"1/25"
DFI002Ø 2"6"
Flangiati PN 10-16 /
Flanged PN 10-16
DFI212DN 658"
DFI003DN 808"
DFI004DN 10010"
COIBENTAZIONE
INSULATION
CBDFI001Ø 1"
CBDFI114Ø 1"1/4
CBDFI112Ø 1"1/2
CBDFI002Ø 2"
CBDFI212DN 65
CBDFI003DN 80
CBDFI004DN 100

Hydrociclonic deposit separator with integrated magnet

Carbon steel

Insulation

Out-of-standard products can be realised according to Customer’s requirements

DIACOM hydraulic compensator

Model
Download
Description
Use
Codice /
Code
Attacchi /
Connections
Corpo /
Body
Portate Indicative /
Approximate Flow Rates
Volume /
Volume
Filettati /
Threaded
C001Ø 1"3"2 m³/h *2.2 l
C114Ø 1"1/44"3.5 m³/h *5 l
C112Ø 1"1/24"5 m³/h *6 l
C002Ø 2"5"8 m³/h *12 l
Flangiati PN 10-16 /
Flanged PN 10-16
C212DN 656"12 m³/h *21 l
C003DN 808"18 m³/h *42 l
C004DN 10010"30 m³/h *84 l
C005DN 12512"50 m³/h *146 l
C006DN 15016"70 m³/h *260 l
C008DN 20020"120 m³/h *548 l
C010 **DN 250800 mm150 m³/h *-
C012 **DN 300950 mm220 m³/h *-
COIBENTAZIONE
INSULATION
CBC001Ø 1"
CBC114Ø 1"1/4
CBC112Ø 1"1/2
CBC002Ø 2"
CBC212DN 65
CBC003DN 80
CBC004DN 100
* Con una perdita
di carico di 100 daPa
With a load loss
of 100 daPa
** Attacchi coassiali
Coaxial connection

Hydraulic compensator with additional functions of air and deposit separator for heating plants

Carbon steel

Insulation

Out-of-standard products can be realised according to Customer’s requirements

Deposit separator

Model
Download
Description
Use
Codice / Code Attacchi / ConnectionsCorpo / Body
Filettati / Threaded
DF001Ø 1"3"
DF114Ø 1"1/44"
DF112Ø 1"1/24"
DF002Ø 2"5"
Flangiati PN 10-16 /
Flanged PN 10-16
DF212DN 656"
DF003DN 808"
DF004DN 10010"
DF005DN 12512"
DF006DN 15016"
DF008DN 20020"
COIBENTAZIONE
INSULATION
CBDF001Ø 1"
CBDF114Ø 1"1/4
CBDF112Ø 1"1/2
CBDF002Ø 2"
CBDF212DN 65
CBDF003DN 80
CBDF004DN 100

Deposit separator with additional functions of air separator for heating plants

Carbon steel

Insulation

Out-of-standard products can be realised according to Customer’s requirements

INAIL safety devices holder

Model
Download
Description
Codice /
Code
Corpo /
Body
Attacchi Principali /
Main Outlet
CPS1142"1"1/4
CPS1122"1/21"1/2
CPS0022"2"
CPS2122"1/22"1/2
Per sapere i diametri delle uscite scaricare il file "DIMENSIONI"
nella sezione download
In order to know the outlet connections, please download the file "SIZES"
in the download area

Not included tools

DIACOL 140 dual opposed

Model
Download
Description
Use
Codice /
Code
Zone /
Zones
Attacchi Principali /
Main Connections
Attacchi Derivazioni /
Outlet Connections
i
C21T2+11"1/21"140 mm
C22T2+21"1/21"140 mm
C31T3+11"1/21"140 mm
C32T3+22"1"140 mm
C33T3+32"1"140 mm
C41T4+12"1"140 mm
C42T4+22"1"140 mm
C51T5+12"1"140 mm

140 mm interaxis dual opposed manifold for heating plant with threaded outlet

Carbon steel

Insulation

Fixing kit

Out-of-standard products can be realised according to Customer’s requirements
